RAD柜式屋顶离心风机
结构特点:
Structural features:
风机采用铝合金框架及铝合金防雨百叶;
The frame of cabinet fan is made of aluminium, the panel adapt waterproof shutter;
采用机翼型叶轮,风叶可调,叶轮材料为铝合金或玻璃纤维增强聚丙烯(PP)。
The impeller designed for air-foil impeller and can be adjusted, it is made of Al or PP.
型号范围:NO.250-1400共17种机号
Model range: no. 250-1400, 17numbers in total
风量范围:832-97000m3/h
Air volume range: 832-97000m3/h
全压范围:45-350Pa
Total pressure range: 45-350Pa
适合用途:广泛用于工厂、仓库、实验室等;可以制作防爆、防腐,送风、净化或消防系列。
Application: It can be used to explosion-proof、anti-corrosin purification or fire proteetion etc.
