CBS-45后倾离心风机

CBS-45-A/C/D风机性能上综合考虑了高压风机压力系数高和中低压风机流量大的特点,解决了以往风机造形上的缺点，使选型风机能保持在最佳工况点范围内。达到高效、节能和结构紧凑的理想状态。

We think over the performance of CBS-45-A/C/D series fan sufficiency, so the fan which you selected runs in the best tone, high efficiency, saving rresources, tight structure is the Virtue of this series fan.

CBS-45-A/C/D风机结构上设有A式C式D式等传动方式,标准系列规格从400-2000共25个机号,机壳部出厂时可制成0°45°90°135°180°共5种,并根据用户需要通过调整机壳部侧板上等分孔进行不同角度的适当微调,由于性能理想、结构紧凑,安装维护方便,故可广泛用于环保除尘、火核发电、冶金、石化及汽车涂装、水坭建筑等行业各种工业气体输送。C/D式带散热叶轮时适用于不超过200℃温度下的炉窑、燃烧器及高温气体循环。特殊按需亦可制成外壳保温风机。

Model CBS-45-A/C/D serial centnifugal fan driven by A/C and D forms. It has 25 sizer for normalizaltion from 400#-2000#. The outlet flange position of fan are fixed five kinds(0°45°90°135°180°). Since the performance well, structure tight and maintenance conveniently. CBS-A/C/D centrifugal fan is suited to dusty equipment, nuclear power plant, metallurgy, petroleum and chemical, automobile paintng and cement factory ect. When the fan driven by c or D form which installed cooling disk is suited in toast oven and drying oven while the temperature less than 200℃. The fan also can be made with heat presercvation casing according to request.
