CBS后倾离心风机

概述

CBS-A/C/D离心通风机是我公司科研人员在充分吸收欧美等先进国家风机技术的基础上,引进先进技术和工艺而研发的单进风离心通风机。

风量范围:840~243536m3/h

风压范围:200~3800Pa

驱动方式:皮带（C），直联（A/D）

机号:355#~2000#

方向角度:可制成顺时针或逆时针,均可制成0°,45°,90°,135°,180°,270°六种角度

用途:可用于排除含液气体;工业厂房排风;防爆排风;汽车工业喷涂;车间排风;电子行业除尘;钢铁行业鼓风;火核发电;石化行业;垃圾焚烧,C、D式带散热叶轮或水冷却时适用于高温环境下的烘烤炉、干燥炉及高温气体循环,介质中所含的尘土及硬质细颗粒不大于150mg/m3等。

CBS-A/C/D可制作成防爆式（CBS-A/C/D）和防腐式（FCBS-A/C/D）

Summary

TDF-A/C/D centrifugal fan is a kind of single inlet centrifugal fan which we developed on the basis of advanced technologies that we’ve absorbed completly and imported from western countries.

Range of air volume: 700~224000 m3/h

Range of air pressure: 200~3800 Pa

Driving method: belt（C）， direct connection

Models:355#~2000#

Direction and angle: can be made to clockwise or anti-clockwise, and both of them can be made to six angle: 0°，45°，90°,135°,180°,270°.

Application: Ventilation of liquid-included air, factory buildings explosion-proof evironment and painting workshop of automobile industry, dedusting in electronic industry, blast in steel industry, fire/nuclear-power generation, petrochemistry industry, waste incineration. When C/D type fans are with cooling impeller or water cooling system, they are avilable for oven/drying-stove in high temperature environment and the circulation of air with hign temperature. Size of dust and hard

particles should be less than 150mg/m3, etc.

CBS-A/C/D can be made to explosion-proof type（CBS-A/C/D）and corrosion-proof type（FCBS-A/C/D）
